256 IALA LED Marine Navigation Aids System AIS Class A Class B

256 IALA LED Marine Navigation Aids System AIS Class A Class B

  • 256 IALA LED Marine Navigation Aids System AIS Class A Class B
256 IALA LED Marine Navigation Aids System AIS Class A Class B
Product Details:
Place of Origin: SHAANXI, CHINA
Brand Name: WelandSignal
Certification: ROHS,CE
Model Number: AIS60
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: USD$1390-1590
Packaging Details: Each has one small carton and 6pcs in one big carton
Delivery Time: 3-7 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20000pcs/month
Contact Now
Detailed Product Description
Light Source: Super Bright Medium Intensity LED Color: Red, Green, Yellow, Blue, White
Voltage: 12VDC,4VDC,48VDC Material: Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection
Working Mode: Flashing, Steady On Peak Intensity: 2500cd Flashing
Waterproof: IP67 Mounting: 4pcs Bolts
Warranty: 5 Years OEM: Color, Flashing Frequency, Logo, Carton Design
Standard: IALA Application: Buoy, Bridge, Light Tower, Boat Navigation Lighting
High Light:

256 IALA LED Marine Navigation Aids

,

Marine Navigation Aids System AIS

,

256 IALA Marine Navigation Aids

256 IALA AIS Class A Class B Program LED Marine Navigation Aids System

Boat navigation lights are not only for the safety of you and your passengers, but also is required by law if you plan on taking your boat out in the evening hours. Navigation lights are also a vital form of communication between boats, to be able to see which direction the boat is traveling, whether it is a sailboat or motor boat, as well as the distance from the observer. At WelandSignal' Marine we pride ourselves on offering the widest selection of marine navigation lights available on the market at the most affordable pricing. Our experts have done significant product research to determine which manufacturers are the most reputable and which products are the most reliable - these are the products you will find at Hodges Marine, where the professionals go for marine supplies and modern boat accessories and technology.



SPECIFICATIONS





256 IALA AIS GPS LED Marine Navigation Aids System



Mechanical Specifications Electrical Specifications



Peak Intensity



10-3000cd Adjusbale Optional AIS



Working Model



256IALA flashin model for slection Lens Material Polycarbonate



Protect Level



IP65 Input Voltage 12VDC;24VDC;48VDC



LED



Super-bright medium intensty Leds Function Optional Synchronization



Temperature



-45℃~70℃ Mounting 4 bolts M6



Automatic Light Control (ALC)



Turn on at night and off at daytime automatically OEM Service

Color: Red, Green, Yellow, Blue, White

Flashing frequency

  • Low power consumption
  • High energy efficiency
  • High flexibility of use
  • Ability to replace batteries
  • LEDs on protected metal core PCB for maximum lifetime
  • LED to monitor over temperature
  • Flexible electronic configuration
  • For offshore platforms, ports and harbours, aquaculture, fixed or floating structures
  • Multiple independent solar/battery configurations possible
  • There are 4 colors to choose from. Colors meet IALA chromaticity requirements



256 IALA LED Marine Navigation Aids System AIS Class A Class B 0




Mariner in the broadcasting region are provided with crucial Message 21 information (as defined by the International Telecommunication Union (ITU)) such as AtoN operational status and positioning.

In addition, the AIS enabled AtoN broadcasts AIS Message 6 received by the designated base station, allowing the operator to monitor the AtoN for solar and battery voltage, flash code setting and light status.

WelandSignalTM is able to support real, synthetic and virtual transmissions. GPS or Beidou are installed when AtoN installed in deep sea.



256 IALA LED Marine Navigation Aids System AIS Class A Class B 1

ADVANTAGES



  • Low power consumption, be compatible with range of WelandSignalTM ’ lanterns.
  • Power management system to ensure solar panel and battery’ life, and alarm for mistakes.
  • Complete AIS solutions displaying accurate positioning & operational information about the AtoN
  • Supports Message 21, 6
  • Capable to communicate with Class A/B
  • Accurate and real-time information
  • Support real, synthetic and virtual transmissions
  • AIS terminal without lantern is available if no visual navaid required

256 IALA LED Marine Navigation Aids System AIS Class A Class B 2

SIZE (mm)



256 IALA LED Marine Navigation Aids System AIS Class A Class B 3







RECENT PROJECTS

______________
Our unique.portable designs ensure navigation lanterns can withstand harsh conditions at sea. All components are housed in rugged, high grade enclosure to ensure long-term performance with no maintenance. Since 2010, WelandSignalTM has finished 32,000 installations over 80 countries.



256 IALA LED Marine Navigation Aids System AIS Class A Class B 4
