Name: Medium Intensity FAA Obstruction Light Flash Red For Aircraft
Brand: WelandSignal
SKU: GZ155
Price: 49 USD
Availability: InStock
Rating: 4.9 (199 reviews)

Home Products Aviation Obstruction Light

Medium Intensity FAA Obstruction Light Flash Red For Aircraft

Product Details:

Place of Origin:	SHAANXI, CHINA
Brand Name:	WelandSignal
Certification:	ROHS,CE
Model Number:	GZ155

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD$49-69
Packaging Details:	Each has one small carton
Delivery Time:	3-7 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	20000pcs/month

Contact Now

Detailed Product Description

Light Source:	Super Bright Medium Intensity LED	Color:	Red, Green, Yellow, Blue, White
Voltage:	110-220VAC,12VDC,4VDC,48VDC	Material:	Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection
Working Mode:	Flashing, Steady On	Peak Intensity:	10cd,32.5cd,300cd
Waterproof:	IP67	Mounting:	4pcs Bolts
Warranty:	5 Years	OEM:	Color, Flashing Frequency, Logo, Carton Design
Standard:	FAA,ICAO	Application:	Tower, Chimney ,tall Buildings, Bridge Aviation Obstruction Lighting Area
High Light:	Medium Intensity FAA Obstruction Light , Aircraft FAA Obstruction Light Flash Red , Medium Intensity faa red obstruction lights

GZ155 Red Flash Led Strobe Lights For Aircrafts increase night visibility of transmission line catenaries near airports, heliports and rivers. These lights mark and illuminate overhead power lines, supporting structures (towers), and high voltage transmission line contact wires. It is an assembly light with multi-LED technology. Beacon dedicated to high voltage lines, it is a long life system (100,000 hours). Its compact design and low weight make it the fastest and easiest way to install on the market.

SPECIFICATIONS

GZ155 Red Flash Led Strobe Lights For Aircraft
Mechanical Specifications		Electrical Specifications
Peak Intensity	10cd,32.5cd,300cd	Structure	Integrated Design
Working Model	Flahing/Steady On	Lens Material	Polycarbonate
Protect Level	IP67	Input Voltage	110-220VAC, 50/60 Hz;12VDC;24VDC;48VDC
LED	Super-bright medium intensty Leds	Function Optional	Synchronization
Temperature	-45℃~70℃	Mounting	4 bolts M6
Automatic Light Control (ALC)	Turn on at night and off at daytime automatically	OEM Service	Color: Red, Green, Yellow, Blue, White Flashing frequency

Medium Intensity FAA Obstruction Light Flash Red For Aircraft 0

KEY FEATURES

Use of a Fresnel lens for even distribution of the light and ensures the light beam is in the scope as required.
Based on LED technology for low power consumption and high efficiency.
Lamp housing – Polycarbonate cover with good anti-impact strength, thermal stability and high transmittance.
Die casting aluminum base with yellow colour powder-coated paint finish (available in red also), provides corrosion resistance and durability.
G3/4”pipe available separately for ease of mount.
Self-contained compartment, with stainless steel wire which is used to secure the unit against falling during maintenance.
Built-in photocell can switch ON/OFF the light at dawn and dusk (optional).
Steady burning or flashing type (no need external controller).

SIZE (mm)

Medium Intensity FAA Obstruction Light Flash Red For Aircraft 1

STANDARS

Medium Intensity FAA Obstruction Light Flash Red For Aircraft 2

Installation

Medium Intensity FAA Obstruction Light Flash Red For Aircraft 3
