Place of Origin: | SHAANXI, CHINA |
Brand Name: | WelandSignal |
Certification: | ROHS, CE |
Model Number: | AFS400 |
Minimum Order Quantity: | 1pc |
---|---|
Price: | USD$149-169 |
Packaging Details: | Each has one small carton and 6pcs in one big carton |
Delivery Time: | 3-7 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 20000pcs/month |
Light Source: | Super Bright LED | Color: | Red, Green, Yellow, Blue, White |
---|---|---|---|
Material: | Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection | Working Mode: | Flashing, Steady On |
Visibility: | 6-7KM | Peak Intensity: | 10-800cd Adjustbale |
Waterproof: | IP68 | Solar Panel: | 3W * 4pcs Mono |
Battery: | 12.8V4AH LiFePO4 Battery | Mounting: | 4pcs Bolts |
Warranty: | 3 Years | OEM: | Color, Flashing Frequency, Logo, Carton Design |
Standard: | FAA,ICAO | Application: | Crane Marking Light, Tower, Chimney ,tall Buildings, Bridge Aviation Obstruction Lighting Area |
High Light: | Aviation Obstruction Light For Bridge,bridge marking L864 Obstruction Light,L864 Bridge Obstruction Light |
L864 Solar Led Aviation Obstruction Light For Bridge Marking is a solar integrated aviation obstruction light that is suitable for use in places that are without electricity. There is no need for maintenance or management and it offers automatic control. This product can continuously operate for seven days without any sunlight.
This product uses an ICAO standardised design with the advantages of shockproof and corrosion resistance. It consists of an aviation light, duty & stand-by controller, silicon solar panel and battery.
This product complies with both ICAO (Annex 14) and FAA standards. The enclosure of this light is made of die casting aluminium (LM6) with a powder coated finish. Other advantages are that it is lightweight, waterproof, shockproof and corrosion resistant.
Key Features
GPS Synchronization
NOTE:
SPECIFICATIONS
L864 Solar Led Aviation Obstruction Light For Bridge Marking
|
|||
Mechanical Specifications | Electrical Specifications | ||
Peak Intensity
|
10-800cd adjustable |
Structure |
Solar Integrated Design Bird deterrent conjoined with lens for not easy to break |
Working Model
|
Flahing/Steady On | Lens Material | Polycarbonate |
Protect Level
|
IP68 | Solar Panel | 3W * 4pcs mono |
Energy Manage System (EMS)
|
Intelligent Microprocessor | Storage Battery | 12.8V4AH LiFePO4 battery |
Temperature
|
-45℃~70℃ | Function Optional | Synchronization |
Continuous Working Hours |
250hours | Mounting | 4 bolts M6 for Mounting |
Automatic Light Control (ALC)
|
Turn on at night and off at daytime automatically | OEM Service |
Color: Red, Green, Yellow, Blue, White Flashing frequency |
SIZE (mm)
Standard
