| Place of Origin: | SHAANXI, CHINA |
| Brand Name: | WelandSignal |
| Certification: | ROHS, CE |
| Model Number: | NFS1803P |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD$399 |
| Packaging Details: | Each has one small carton |
| Delivery Time: | 3-7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 20000pcs/month |
| Light Source: | Super Bright LED | Color: | Red, Yellow ,green ,blue, White |
|---|---|---|---|
| Material: | Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection | Design Idea: | Integrated Construction Bird Deterrent Conjoined With Lens For Not Easy To Break |
| Visibility: | 10nm | Waterproof: | IP65 |
| Solar Panel: | 4W * 7pcs Mono | Battery: | 12.8V20AH LiFePO4 Battery |
| Mounting: | 4pcs Bolts | Warranty: | 3 Years |
| Standard: | IALA 256 Flashing Pattens | Application: | Vessel Navigation Light, Boat Navigation Lantern, Masthead Light, Stern Light, Side Light, All-round Light, 6nm Solar Boat Navigation Light |
| High Light: | 10nm Visibility Bridge Navigation Lights,Solar LED Bridge Navigation Lights,10nm Visibility marine navigation lantern |
||
10nm Visibility Bridge Marking Solar Led Lanterns are used for buoys, lighthouses and any other offshore sites where sea/river navigation is safe.
This LED Marine Lantern is a completely self-contained lantern. Four (4) solar panels are integrated into the assembly and installed to collect sunlight from all angles. Using ultra-high-intensity LED as the light source makes the performance better. Best Lanterns for Buoys
GSM monitoring is available as an optional feature, it automatically sends text messages when a failure occurs.
SPECIFICATIONS
|
10nm Visibility Bridge Marking Solar Led Lanterns
|
|||
| Mechanical Specifications | Electrical Specifications | ||
|
Peak Intensity
|
1500~2500cd adjustable |
Structure |
Solar Integrated Design Bird deterrent conjoined with lens for not easy to break |
|
Working Model
|
Flashing | Lens Material | Polycarbonate |
|
Protect Level
|
IP68 | Solar Panel | 7W * 4pcs mono |
|
Energy Manage System (EMS)
|
Intelligent Microprocessor | Storage Battery | 12.8V20AH LiFePO4 battery |
|
Temperature
|
-45℃~70℃ | Function Optional | Location |
|
Continuous Working Hours |
250hours | Mounting | 4 bolts M6 for Mounting |
|
Automatic Light Control (ALC)
|
Turn on at night and off at daytime automatically | Standard |
IALA 256 flashing pattens |
NOTE:
KEY FEATURES
1. Based on LED technology, the color conforms to IALA Recommendations E-200-1. LED technology reduces maintenance time and cost
2. PC shell, anti-ultraviolet, anti-shock, anti-corrosion.
3. Anti-bird nails are optional.
4. Powder-coated die-cast aluminum base.
5. 4-sided monocrystalline silicon solar panel, the conversion efficiency is better than that of polycrystalline silicon.
6. The vertical angle of 4 solar panels is adjustable.
7. On/Off button interface.
8. Solar panels as photo cells for day/night operation (dusk to dawn)
9. 256 flicker rates in line with IALA, controlled by remote control
SIZE (mm)
OPERATION
4pcs of Solar panels are foldable for better sunshine absorption.
