| Place of Origin: | SHAANXI, CHINA |
| Brand Name: | WelandSignal |
| Certification: | ROHS, CE |
| Model Number: | NFS1803L |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD$199 |
| Packaging Details: | Each has one small carton |
| Delivery Time: | 3-7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 20000pcs/month |
| Light Source: | Super Bright LED | Color: | Red, Yellow ,green ,blue, White |
|---|---|---|---|
| Material: | Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection | Design Idea: | Integrated Construction Bird Deterrent Conjoined With Lens For Not Easy To Break |
| Visibility: | 7nm | Waterproof: | IP68 |
| Solar Panel: | 4W * 4pcs Mono | Battery: | 12.8V4AH LiFePO4 Battery |
| Mounting: | 4pcs Bolts | Warranty: | 3 Years |
| Standard: | IALA 256 Flashing Pattens | Application: | Vessel Navigation Light, Boat Navigation Lantern, Masthead Light, Stern Light, Side Light, All-round Light, 6nm Solar Boat Navigation Light |
| High Light: | Solar LED Bridge Navigation Lights,Bridge Navigation Lights 7nm Visibility,7nm Visibility Solar Navigation Lights |
||
Safe Water Buoy LED Bridge Light is an LED bridge light. It is designed with 4pcs of Solar panels are foldable for better sunshine absorption.
They are specifically designed to clearly mark bridges and structures that extend over navigable waterways. Widely used in the US, the NFS1803L series is designed to provide excellent visibility up to 5NM and works with existing power sources.
The light is available in a 180º fan-shaped red model or a 360º green model with a fixed installation as standard. These luminaires also have a range of factory-set flash characteristics and sector requirements.
The NFS1803L series is also available as a complete solar/battery system to comply with the requirements of regional governing bodies such as the U.S. Coast Guard, or IALA recommendations for fixed bridge markings in navigable waters.
SPECIFICATIONS
|
Safe Water Buoy LED Bridge Light
|
|||
| Mechanical Specifications | Electrical Specifications | ||
|
Peak Intensity
|
1500cd with 6nm visibility, adjustable |
Structure |
Solar Integrated Design Bird deterrent conjoined with lens for not easy to break |
|
Working Model
|
Flashing | Lens Material | Polycarbonate |
|
Protect Level
|
IP68 | Solar Panel | 4W * 4pcs mono |
|
Energy Manage System (EMS)
|
Intelligent Microprocessor | Storage Battery | 12.8V4AH LiFePO4 battery |
|
Temperature
|
-45℃~70℃ | Function Optional | Location,256IALA flashing patterns |
|
Continuous Working Hours |
250hours | Mounting | 4 bolts M6 for Mounting |
|
Automatic Light Control (ALC)
|
Turn on at night and off at daytime automatically | Standard |
IALA |
NOTE:
KEY FEATURES
1. Based on LED technology, the color conforms to IALA Recommendations E-200-1. LED technology reduces maintenance time and cost
2. PC shell, anti-ultraviolet, anti-shock, anti-corrosion.
3. Anti-bird nails are optional.
4. Powder-coated die-cast aluminum base.
5. 4-sided monocrystalline silicon solar panel, the conversion efficiency is better than that of polycrystalline silicon.
6. The vertical angle of 4 solar panels is adjustable.
7. On/Off button interface.
8. Solar panels as photo cells for day/night operation (dusk to dawn)
9. 256 flicker rates in line with IALA, controlled by remote control
SIZE (mm)
OPERATION
4pcs of Solar panels are foldable for better sunshine absorption.
Recent Projects
Our unique.portable designs ensure navigation lanterns can withstand harsh conditions at sea. All components are housed in rugged, high grade enclosure to ensure long-term performance with no maintenance. Since 2010, WelandSignalTM has finished 32,000 installations over 80 countries.
