5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright

5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright

  • 5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright
  • 5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright
  • 5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright
5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright
Product Details:
Place of Origin: SHAANXI, CHINA
Brand Name: WelandSignal
Certification: ROHS, CE
Model Number: CXHX-2-4
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: USD$199
Packaging Details: Each has one small carton
Delivery Time: 3-7 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20000pcs/month
Contact Now
Detailed Product Description
Light Source: Super Bright LED Color: 112.5°Red + 112.5°Green + 135°White=360°
Material: Polycarbonate, Shock-resistance, Anti-UV, Salt And Dust Self-protection Working Mode: Steady On
Visibility: 5nm Waterproof: IP68
Solar Panel: 3W*4pcs Mono Battery: 12.8V 4AH LiFePO4 Battery
Mounting: 4pcs Bolts Warranty: 3 Years
Standard: UL 1104 & COLREG-72 Application: Vessel Navigation Light, Boat Navigation Lantern, Masthead Light, Stern Light, Side Light, All-round Light, 6nm Solar Boat Navigation Light
High Light:

5nm Solar Powered Anchor Light

,

Steady On Solar Powered Anchor Light

,

5nm solar powered boat navigation lights

Welandsignal' Solar LED Navigation Lights On A Boat has become the most classic solar LED light in the global marine navigation field. Due to its independence, reliability and durability, it is also the perfect example for a variety of warning applications. It can be installed in minutes and requires no maintenance or repairs for up to five years. It meets the requirements of IALA-AISM.

The LED marine light is one of the most advanced of its kind and incorporates many innovative features designed to make the unit very user friendly.World class LED lens optical design to achieve precise intensity and sector requirements with a single LED light source.This design helps achieve lower operating currents compared to alternative LED marine lights - making the unit super efficient.Four (4) premium solar modules are integrated into the assembly and installed to collect sunlight from all angles.The lamp has a built-in GPS module (optional), and multiple lamps can be synchronized at the same time.



SPECIFICATIONS





Solar LED Navigation Lights On A Boat



Mechanical Specifications Electrical Specifications



Peak Intensity



1500`2500cd adjustable

Structure

Solar Integrated Design

Bird deterrent conjoined with lens for not easy to break



Working Model



Steady On Lens Material Polycarbonate



Protect Level



IP68 Solar Panel 4W * 4pcs mono



Energy Manage System (EMS)



Intelligent Microprocessor Storage Battery 12.8V4AH LiFePO4 battery



Temperature



-45℃~70℃ Function Optional Location



Continuous Working Hours

250hours Mounting 4 bolts M6 for Mounting



Automatic Light Control (ALC)



Turn on at night and off at daytime automatically Light Angel

112.5°Red + 112.5°Green + 135°White=360°



5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright 0



Post a lookout. Designate someone to watch for dangers that may come from any direction.

Maintain a safe speed. Except where speed is restricted by regulation or the waterway is marked by a “No Wake” or “Slow Speed” Aid, you must judge “safe speed” for yourself, taking into account visibility, vessel traffic, your boat’s ability tomaneuver, and the weather conditions.
Avoid a collision. The Rules of the Road include the actions to take when encountering another vessel on the water. Some of the most common situations you may encounter are: overtaking, meeting head on, and crossing the bow of another vessel. In each case, the boat designated as the “give-way” vessel is required to yield to the other boat, while the boat designated as the “stand-on” vessel should maintain its course
and speed.​

Action(s): The give-way vessel (bottom) can pass on either side of the stand-on vessel (top).

Sound signals, inland: Passing portside requires two short (1-second) blasts on the horn signaling the overtaking boat’s intention, and two short blasts for the stand-on vessel’s agreement. Passing to starboard requires one short blast for intent and agreement.

Sound signals, international: Passing portside requires two prolonged (4-6 seconds) and two short blasts for the overtaking boat’s intention, two short blasts for the stand-on vessel’s agreement. Passing to starboard requires two prolonged and one short blast for intention. An agreement signal is only required when operating in a narrow channel or fairway; then the following blast pattern signals your agreement: one prolonged/one short/one prolonged/one short.

5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright 1

NOTE:

  • Year-round, unrestricted solar exposure is critical to long-term performance. Shade dramatically reduces the ability of the light to charge its battery.
  • Charge every 3 months when storing.






STANDARD

5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright 2

5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright 3





5nm Visibility Steady On Solar Powered Anchor Light Type Super Bright 4
